Fabric properties
Semi transparent
27% Polyester, 73% PVC
445 g/m²
0.54 mm
245 cm
250 cm
Features / Technical properties
8
Flame retardant
Optimised for workstations
Antimicrobial (ASTM - SGS)
Applicable in humid areas
Oeko-Tex, Greenguard
Special colours from 5’000 m
Washing instructions
Optical and solar coefficients (± 5%, DIN EN 410)
| Colour | |||||||
|---|---|---|---|---|---|---|---|
| Colour 1 | Tv(%) 4.7 | Ts(%) 5.0 | Rs(%) 65.0 | As(%) 30.0 | Tuv(%) 4.0 | Fc() 0.51 | gtot() 0.37 |
| Colour 2 | Tv(%) 3.0 | Ts(%) 6.0 | Rs(%) 46.0 | As(%) 48.0 | Tuv(%) 4.0 | Fc() 0.63 | gtot() 0.45 |
| Colour 3 | Tv(%) 4.9 | Ts(%) 5.0 | Rs(%) 45.0 | As(%) 50.0 | Tuv(%) 4.0 | Fc() 0.64 | gtot() 0.46 |
Fc + gtot: Value calculated with glass: 0.72 / Ug = 1.6 W/m² K, DIN EN 13363-1
Classification of solar shading devices (DIN EN 14501:2021)
| Colour | Glare control | Privacy at night | Sight contact with the outside | Daylight utilisation |
|---|---|---|---|---|
| Colour 1 | Glare control 2 | Privacy at night 2 | Sight contact with the outside 2 | Daylight utilisation 2 |
| Colour 2 | Glare control 1 | Privacy at night 2 | Sight contact with the outside 2 | Daylight utilisation 2 |
| Colour 3 | Glare control 2 | Privacy at night 2 | Sight contact with the outside 2 | Daylight utilisation 1 |
0: No effect, 1: Low effect, 2: Medium effect, 3: High effect, 4: Very high effect
Downloads
Flame retardant
On request:
NFPA 701
Certificates
On request:
Greenguard
ASTM
Inspiration
