Fabric properties
| 900 | 929 | |
| Semi transparent | ||
| Polyester Trevira CS | ||
| 512 g/m² | 545 g/m² | |
| 0.80 mm | 0.85 mm | |
| 460 cm | ||
 | 500 cm | |
Features / Technical properties
| 900 | 929 | |
| 5-6 | 6-7 | |
| Alpha-w = 0.60 | ||
| Flame retardant | ||
 | Oeko-Tex | |
 | Special colours from 1’000 m | |
Washing instructions
Optical and solar coefficients (± 5%, DIN EN 410)
| Colour | |||||||
|---|---|---|---|---|---|---|---|
| Colour 900 | Tv(%) 25.1 | Ts(%) 24.1 | Rs(%) 72.7 | As(%) 3.2 | Tuv(%) 0.00 | Fc() 0.47 | gtot() 0.34 |
| Colour 929 | Tv(%) 3.4 | Ts(%) 12.6 | Rs(%) 53.3 | As(%) 34.1 | Tuv(%) 0.00 | Fc() 0.59 | gtot() 0.42 |
Fc + gtot: Value calculated with glass: 0.72 / Ug = 1.6 W/m² K, DIN EN 13363-1
Classification of solar shading devices (DIN EN 14501:2021)
| Colour | Glare control | Privacy at night | Sight contact with the outside | Daylight utilisation |
|---|---|---|---|---|
| Colour 900 | Glare control 0 | Privacy at night 2 | Sight contact with the outside 0 | Daylight utilisation 2 |
| Colour 929 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 1 |
0: No effect, 1: Low effect, 2: Medium effect, 3: High effect, 4: Very high effect
