Fabric properties
Semi transparent
100% recycl. polyester
215 g/m²
0.55 mm
315 cm
250 cm, 320 cm
Features / Technical properties
7
Flame retardant
Applicable in humid areas
Digital printing
Oeko-Tex, Cradle to Cradle
Special colours from 400 m
Washing instructions
Optical and solar coefficients (± 5%, DIN EN 410)
| Colour | |||||||
|---|---|---|---|---|---|---|---|
| Colour 1 | Tv(%) 33.1 | Ts(%) 34.2 | Rs(%) 60.4 | As(%) 5.4 | Tuv(%) 35.5 | Fc() 0.56 | gtot() 0.40 |
| Colour 4 | Tv(%) 8.5 | Ts(%) 21.1 | Rs(%) 37.2 | As(%) 41.7 | Tuv(%) 7.5 | Fc() 0.70 | gtot() 0.50 |
| Colour 6 | Tv(%) 4.6 | Ts(%) 17.9 | Rs(%) 32.2 | As(%) 49.9 | Tuv(%) 4.5 | Fc() 0.73 | gtot() 0.52 |
| Colour 8 | Tv(%) 3.1 | Ts(%) 16.7 | Rs(%) 29.3 | As(%) 54.0 | Tuv(%) 3.5 | Fc() 0.74 | gtot() 0.54 |
Fc + gtot: Value calculated with glass: 0.72 / Ug = 1.6 W/m² K, DIN EN 13363-1
Classification of solar shading devices (DIN EN 14501:2021)
| Colour | Glare control | Privacy at night | Sight contact with the outside | Daylight utilisation |
|---|---|---|---|---|
| Colour 1 | Glare control 0 | Privacy at night 2 | Sight contact with the outside 0 | Daylight utilisation 3 |
| Colour 4 | Glare control 4 | Privacy at night 2 | Sight contact with the outside 2 | Daylight utilisation 1 |
| Colour 6 | Glare control 4 | Privacy at night 2 | Sight contact with the outside 2 | Daylight utilisation 1 |
| Colour 8 | Glare control 4 | Privacy at night 2 | Sight contact with the outside 2 | Daylight utilisation 1 |
0: No effect, 1: Low effect, 2: Medium effect, 3: High effect, 4: Very high effect
Downloads
Flame retardant
On request:
Class 1 (UNI 8456)
B1 (DIN 4102-1)
M1 (NF P 92-503/5/7)
Certificates
On request:
Cradle to Cradle
